OBDMATE OM126
INQUIRY
With Good Performance
Code Reader , OBDMATE OM126 OBDII OBD2 Scanner Car Engine Fault Code Reader Auto Check Engine Light CAN Automotive Diagnostic Scan Tool.
Product Function
1.Read codes
2.Erase codes
3.I/M Readiness
4.Data stream
5.Freeze frame
6.O2 sensor test
7.On-Board Monitoring
8.Evap system test
9.Vehicle information
10. Built-in OBD II Fault code look-up library
11.Software upgrade via Internet
Product Features
- Large color screen display ,Fashionable design, Easy to operate
- Graphical display data stream
- I/M Readiness Key--check State Emissions readiness
- Read,records&playback DTC and vehicle information
- Support more data (Data stream / freeze frame) for compression ignition vehicles
- Customize Languages -Multilingual menu options and code definitions ( English, Spanish, French, German, Russia.....)
Range of Diagnose
Works on all after 1996 and newer vehicles(OBD II&CAN)
Supports ALL OBD II protocols: CAN, J1850 PWM, J1850 VPW, ISO9141 and KWP2000.
Technical parameters
| Display： | 2.4 inch TFT,320*240LCD |
| Operating Voltage： | 12V DC |
| Operating Temperature： | 0 to 60°C (32 to 140 F°) |
| Storage Temperature： | -20 to 70°C (-4 to 158 F°) |
| External Power： | 8.0 to 18.0 V power provided via vehicle battery |
| Weight： | NW: 0.23kg (0.57lb), GW: 0.35kg (0.77lb) |
