OBDMATE® OM301

INQUIRY

OBDMATE® OM301

A Necessary Aid for Family Auto Maintenance

OBD II Functions

  • Read Codes
  • Clear Codes
  • I/M Readiness
  • Live Data
  • Freeze Frame
  • O2 Sensor Test
  • On-board Monitoring
  • EVAP System Test
  • Vehicle Information



Product Features

  • 2.4” TFT true color display.
  • User-friendly design for effortless operation.
  • Built-in DTC library with over 40,000 code definitions.
  • Real-time graphic live data display.
  • QR-code based reports and wireless printing.
  • 10-Language Support (English, French, Spanish, German, Italy, Russia, Finland, Polish, Netherlands, and Portuguese).


Supports Models

  • Works on most 2000 and newer OBDII compliant US, European, and Asian vehicles.
  • Supports all OBDII protocols including CAN, J1850PWM, J1850VPW, ISO9141 and KWP2000.
  • Supports most vehicles with OBD 12V 16-pin connector after 2000.

    • Specifications

    Display 2.4” LCD, 320*240 pixels TFT true color display
    Operating Temperature 0 to 60°C (32 to 140°F)
    Storage Temperature -20 °C to 70°C (-4 to 158°F)
    External Power 8.0 to 18.0 V power provided via vehicle battery
    Dimensions 142 x 78 x 24 mm
